Reference values
| Nominal thickness mm | Conventional density kg/dm3 | Max core loss value P15/50 – W/kg |
Min induction B50 T | |
|---|---|---|---|---|
|
0.35
|
B35A210
|
7.60
|
2.10
|
1.62
|
|
B35A230
|
7.60
|
2.30
|
1.62
|
|
|
B35A250
|
7.60
|
2.50
|
1.62
|
|
|
B35A270
|
7.65
|
2.70
|
1.62
|
|
|
B35A300
|
7.65
|
3.00
|
1.62
|
|
|
B35A360
|
7.65
|
3.60
|
1.63
|
|
|
B35A440
|
7.70
|
4.40
|
1.64
|
|
|
B35A550
|
7.75
|
5.50
|
1.64
|
|
|
0.50
|
B50A230
|
7.60
|
2.30
|
1.62
|
|
B50A250
|
7.60
|
2.50
|
1.62
|
|
|
B50A270
|
7.60
|
2.70
|
1.62
|
|
|
B50A290
|
7.60
|
2.90
|
1.62
|
|
|
B50A310
|
7.65
|
3.10
|
1.62
|
|
|
B50A350
|
7.65
|
3.50
|
1.62
|
|
|
B50A400
|
7.65
|
4.00
|
1.63
|
|
|
B50A470
|
7.70
|
4.70
|
1.64
|
|
|
B50A530
|
7.70
|
5.30
|
1.65
|
|
|
B50A600
|
7.75
|
6.00
|
1.66
|
|
|
B50A700
|
7.80
|
7.00
|
1.70
|
|
|
B50A800
|
7.80
|
8.00
|
1.70
|
|
|
B50A1000
|
7.85
|
10.00
|
1.70
|
|
|
B50A1300
|
7.85
|
13.00
|
1.70
|
|
|
0.65
|
B65A470
|
7.65
|
4.70
|
1.64
|
|
B65A600
|
7.75
|
6.00
|
1.64
|
|
|
B65A700
|
7.75
|
7.00
|
1.65
|
|
|
B65A800
|
7.80
|
8.00
|
1.69
|
|
|
B65A1000
|
7.80
|
10.00
|
1.69
|
|
|
B65A1300
|
7.85
|
13.00
|
1.69
|
|
|
0.35
|
B35AH230
|
7.65
|
2.30
|
1.66
|
|
B35AH250
|
7.65
|
2.50
|
1.67
|
|
|
B35AH300
|
7.70
|
3.00
|
1.69
|
|
|
0.50
|
B50AH300
|
7.65
|
3.00
|
1.67
|
|
B50AH350
|
7.70
|
3.50
|
1.70
|
|
|
B50AH470
|
7.75
|
4.70
|
1.72
|
|
|
B50AH600
|
7.75
|
6.00
|
1.72
|
|
|
B50AH800
|
7.80
|
8.00
|
1.74
|
| A-Coating | H-Coating | K-Coating | |
|---|---|---|---|
|
Coating type
|
semi organic
|
semi organic
|
semi organic
|
|
Composition
|
inorganic, mainly organic, resin included
|
inorganic, mainly organic, resin included
|
inorganic, mainly organic, resin included
|
|
Thickness
|
abt. 0.3 μm
|
abt. 0.7 μm
|
abt. 0.5 μm
|
|
Heat resistance
|
800°C heat resistance in inoxidate eliminating stress by annealing
|
inapplicable to eliminate stress by annealing
|
750°C heat resistance in inoxidate eliminating stress by annealing
|
|
Cold resistance
|
Freon resistance R22, R134a without change
|
Freon resistance R22, R134a without change
|
Freon resistance R22, R134a without change
|
|
Corrosion resistance
|
good
|
excellent
|
excellent
|
Reference table of standards
| Q/BQB480 | JIS C2552-86 | AISI | EN10106 | ||||
|---|---|---|---|---|---|---|---|
|
Thickness
mm |
Designation
|
Core loss
W/kg at 1.5T/50 Hz |
Designation
|
Core loss
W/kg at 1.5T/50 Hz |
Designation
|
Designation
|
Core loss
W/kg at 1.5T/50 Hz |
|
0.35
|
B35A230
|
2.30
|
35A230
|
2.30
|
|
M235-35A
|
2.35
|
|
B35A250
|
2.50
|
35A250
|
2.50
|
M-15
|
M250-35A
|
2.50
|
|
|
B35A270
|
2.70
|
35A270
|
2.70
|
M-19
|
M270-35A
|
2.70
|
|
|
B35A300
|
3.00
|
35A300
|
3.00
|
M-22/M-27
|
M300-35A
|
3.00
|
|
|
B35A440
|
4.40
|
35A440
|
4.40
|
|
|
|
|
|
0.50
|
B50A250
|
2.50
|
50A250
|
2.50
|
|
M250-50A
|
2.50
|
|
B50A270
|
2.70
|
50A270
|
2.70
|
|
M270-50A
|
2.70
|
|
|
B50A290
|
2.90
|
50A290
|
2.90
|
M-15
|
M290-50A
|
2.90
|
|
|
B50A310
|
3.10
|
50A310
|
3.10
|
M-19
|
M310-50A
|
3.10
|
|
|
B50A350
|
3.50
|
50A350
|
3.50
|
M-36
|
M350-50A
|
3.50
|
|
|
B50A400
|
4.00
|
50A400
|
4.00
|
M-43
|
M400-50A
|
4.00
|
|
|
B50A470
|
4.70
|
50A470
|
4.70
|
M-45
|
M470-50A
|
4.70
|
|
|
B50A530
|
5.30
|
|
|
M530-50A
|
5.30
|
||
|
B50A600
|
6.00
|
50A600
|
6.00
|
|
M600-50A
|
6.00
|
|
|
B50A700
|
7.00
|
50A700
|
7.00
|
M-47
|
M700-50A
|
7.00
|
|
|
B50A800
|
8.00
|
50A800
|
8.00
|
|
M800-50A
|
8.00
|
|
|
B50A1000
|
10.00
|
50A1000
|
10.00
|
|
M940-50A
|
9.40
|
|
